YOKOGAWA F3NC01-0N Positioning Module with Absolute Encoder

The YOKOGAWA F3NC01-0N is an advanced positioning module designed for industrial automation systems. Featuring rapid startup time and precise velocity control, it offers robust performance and reliability.

SKU: 14123979 Category: Tags: , , ,

Description

Startup Time:6 ms max.

Control Velocity Output:-10 to 10 V

Data Backup:Backup using the CPU module

External Contact Output:Servo on, driver reset and brake off

Encoder Type:Absolute encoder and incremental encoder (phase A/B)

Encoder Frequency:Line driver up to 2 Mpps in 4-time multiplication mode

Control System:Semi-closed loop control based on encoder feedback

    The YOKOGAWA F3NC01-0N positioning module is an essential component for industrial automation systems. It features a maximum startup time of just 6 milliseconds, ensuring swift response times for critical operations. With its versatile velocity control output ranging from -10 to 10 volts, it provides accurate and responsive control for various applications. The module includes robust data backup capabilities, utilizing the CPU module for seamless operation without data loss. Additionally, it supports external contact outputs for servo activation, driver reset, and brake deactivation, enhancing operational flexibility. Equipped with an incremental encoder (phaseA/B), this module achieves a maximum line driver speed of up to 2 million pulses per second, enhanced by a 4-time multiplication mode for increased precision. The semi-closed loop control system, based on encoder feedback, ensures consistent and reliable performance. Furthermore, the module supports external contact inputs for limit switches, driver alarms, and homing functions, making it suitable for a wide range of industrial environments.

YOKOGAWA F3NC01-0N

YOKOGAWA F3NC01-0N

YOKOGAWA F3NC01-0N
