Description
XV-102-B6-35TQR-10-PLC is a touch screen processor module/control panel produced by Eaton
1、 Product Overview
This touch screen integrates PLC (Programmable Logic Controller) functions and is a commonly used component in industrial automation systems. It provides an intuitive user interface that enables users to conveniently monitor and control automated processes.
2、 Main features
Color touch screen:
Display screen type: color display, TFT.
Touch technology: resistive touch.
Quantity of colors: 64k colors.
Screen diagonal: 3.5 inches.
Resolution: QVGA, 320 × 240 pixels.
Vertical format: supported.
Backlight illumination: LED, dimmable through software.
Operating System and Functions:
Operating System: Windows CE 5.0.
Function: HMI-PLC (Integrated SPS Function).
Supports Ethernet interfaces, USB devices, SD card slots, etc.
It has archiving function, communication function, etc.
Physical characteristics:
Insulated casing and front panel.
Protection level: IP65 (compliant with IEC/EN 60529, EN50178, VBG 4 standards).
Heat dissipation: 5W.
Processor: RISC CPU, 32-bit, 400MHz.
Memory: 64MB DRAM (for operating system, program, and data storage), NAND Flash (for data backup), approximately 32K bytes of NVRAM (for data retention).
Interface and Communication:
Built in interfaces: 1 Ethernet 10/100 Mbps, 1 RS232, 1 USB device, 1 CANopen/EasyNet.
Optional interface: SD card slot (for data backup and expansion).
Other features:
Support remote control.
It has alarm function, and the alarm types include light alarm, etc.
Support vector graphics display.
Provide multiple screens for users to choose from and configure.
3、 Application Fields
The XV-102-B6-35TQR-10-PLC touch screen processor module/control panel is widely used in the field of industrial automation, such as manufacturing, energy, transportation, etc. As an important control component, it can achieve remote monitoring, fault diagnosis, parameter setting and other functions of equipment, improve production efficiency, and reduce maintenance costs.
