Description
WOODWARD 9907-149 is a digital governor designed for use in equipment such as industrial-scale steam turbines, small turbine generators, or utility turbine expander modules. It operates the steam turbine by using a pair of actuators to drive the intake valve.
The digital governor is a device that regulates the speed of the DC motor, its upper end is connected with the AC power supply, and the lower end is connected with the DC motor. It converts alternating current into two output DC power supplies, one input to the DC motor to sharpen the magnet (stator), one input to the DC motor armature (rotor). The speed of DC motor is adjusted by controlling the armature DC voltage.
In addition, the WOODWARD 9907-149 is equipped with a 32-bit microprocessor to control the turbine. The panel displays two lines of text, each of 24 characters.
When using WOODWARD 9907-149, it is necessary to write configuration and control programs according to specific industrial application scenarios and actual needs. During operation, the governor will automatically adjust and stabilize according to the actual control requirements to ensure the normal operation of the turbine and the accurate control of the output power.
The WOODWARD 505 digital governor is mainly used in industrial applications such as steam turbines, small turbine generators or utility turbine expansion modules. It can control the speed and output power of the steam turbine, has the characteristics of high precision, high stability, fast response, etc., and can adapt to different types of steam turbines and operating environments.
In the application scenario, the WOODWARD 9907-149 digital governor converts the speed signal of the turbine into the oil pressure signal by connecting the sensor and the actuator, and then adjusts the intake or exhaust volume of the turbine through the hydraulic system to achieve stable operation of the turbine and accurate control of the output power. At the same time, it also provides a variety of control functions, such as automatic start sequencing of hot start and cold start, temperature input options, critical speed avoidance, external alarm input, DI trip input, etc., can meet the control needs of different industrial application scenarios.
