Description
Frequency Range:up to 50 MHz
Waveform Memory Depth:16 kpts
Resolution:14 bits
Output Amplitude:+/-10 Vpp
Phase Resolution:0.088 degrees
Channel Count:2 Channels
The Tektronix 5A22N is designed for precise and flexible signal generation, making it an indispensable tool for engineers and researchers. Its high-frequency range and wide output amplitude ensure that a variety of signals can be accurately produced.
With a 14-bit resolution, the device ensures minimal distortion and maximum fidelity in the generated waveforms. This is particularly important in applications where signal integrity is critical.
The instrument supports a wide array of waveform types, including sine, square, triangle, ramp, noise, and arbitrary waveforms. This versatility allows users to simulate a broad spectrum of conditions for thorough testing and analysis.
The memory depth of 16 kSamples enables complex waveform generation and long-duration signal simulations, which are crucial for detailed testing scenarios.
Equipped with two output channels, the Tektronix 5A22N can handle multi-channel applications efficiently, enhancing its utility in various industrial settings.
