Schneider Electric 140CPU67160S Modicon CPU module 140CRA93100

Warranty: 365 days
Quality: Original module
Condition: Brand new/used
Warehouse: from stock
Delivery time: Delivery within 3 days after payment
Email: 3048602330@qq.com

Category: Tag:

Description

Schneider Electric 140CPU67160S Modicon CPU module 140CRA93100

Brand/Manufacturer Schneider/Modicon
Model 140CPU67160S
Part No
Place of Origin FRANCE
Product Name CPU Module
Description Unity Hot Standby processor with multimode Ethernet
Colour Red
Max Connections 1 Modbus Plus – Local
1 Serial Modbus (RS232/485Modbus/ASCII)
1 Ethernet TCP/IP – local
6 USB-Local
CPU Clock Speed 266 MHz
Dimennsions 8.9cm x 8.2cm x 14.4cm
Weight 0.85kg

Memory Description:Extensible 7168 Kb – program with PCMCIA card,Expandable 8 MB – File storage with PCMCIA card,Internal RAM 1024 kB – 512 kB of data stock

Required bus current:2500 mA

Battery life:Ten years

PACKING UNIT

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 11.0 cm
Package 1 Width 19.0 cm
Package 1 Length 32.5 cm
Package 1 Weight 1.391 kg
Unit Type of Package 2 S03
Number of Units in Package 2 2
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 2.922 kg


140CPU53414AC 140CPU53414B 140CPU53414BC 140CPU53414C 140CPU53414U

140CPU53414UC 140CPU65150 140CPU65150C 140CPU65160 140CPU65160C

140CPU65160S 140CPU65260 140CPU65260C 140CPU65860 140CPU65860C

140CPU67060 140CPU67060C 140CPU67160 140CPU67160C 140CPU67160S


High-frequency inverter rectifier welder power supply is a new type of welder power supply, which can save materials. It represents the development direction of current welder power supply. Because of the commercialization of IGBT large capacity module, this kind of power supply has a broad application prospect.

AC-DC-AC-DC (AC-Dc-AC-DC) transformation method is adopted for the power supply of inverter welding machine. The 50Hz AC is converted into DC by full bridge rectification, and the PWM high frequency conversion part composed of IGBT inverts the DC into a high frequency rectangular wave of 20kHz, which becomes stable DC after high-frequency transformer coupling, rectification and filtering, and the power supply arc is used.

Due to the poor working conditions of the welder power supply, it is frequently in the alternating changes of short circuit, arc burning and open circuit, so the reliability of the high frequency inverter rectifier welder power supply has become the key problem, and the user is concerned about the problem. Using microprocessor as pulse width modulation (PWM) controller, through the extraction and analysis of multi-parameters, multi-information, to predict the purpose of various working states of the system, and then in advance to make adjustments and processing of the system, to solve the current high power IGBT inverter reliability.

Foreign inverter welding machines have been able to achieve rated welding current 300A, load duration rate 60%, full load voltage 60~75V, current adjustment range 5~300A, weight
