Description
Manufacturer:Allen-Bradley
Model:1786-TPYR
Module Type:Thermocouple Input Module
Input Channels:8 channels
Temperature Range:-200°C to +850°C
Accuracy:±0.1% of reading ±1°C
Response Time:<50ms
Power Supply:24V DC
Operating Temperature:-40°C to +85°C
Dimensions:Width: 10mm x Height: 100mm x Depth: 90mm
Weight:0.3kg
Communication Protocol:Modbus RTU/ASCII
Designed for industrial automation systems, the Allen Bradley 1786-TPYR Thermocouple Input Module delivers high accuracy and reliability for temperature measurement. Its robust construction ensures long-term durability even in harsh environments.
With 8 thermocouple input channels, this module supports various types of thermocouples, including K, J, T, R, S, B, N, and E. This versatility makes it suitable for a wide range of industrial applications.
The 1786-TPYR features a high-resolution 14-bit ADC for precise temperature readings. The accuracy of ±0.5°C or ±0.2% of reading ensures that your process remains within tight tolerance limits.
Fast response time of less than 10 milliseconds allows for real-time monitoring and quick adjustments to changing conditions. The module communicates via Modbus RTU over RS485, ensuring seamless integration with existing industrial networks.
The Allen Bradley 1786-TPYR is built to withstand operating temperatures from -40°C to 85°C, making it ideal for use in extreme environments. Its compact design allows for easy installation in crowded control panels, saving valuable space.
