NI SCXI-1520 High-Speed Data Acquisition Module

NI SCXI-1520 High-Speed Data Acquisition Module

Reliance Electric 0-60002-5 Power Tech DC Module: Drive BoardsSIEMENS 6ES7132-4BB00-0AA0: Industrial PLC Output Module, for Precise Control & Automation Solutions

The NI SCXI-1520 is a high-performance analog input module designed for industrial automation and control systems. It provides precise measurements for a wide range of applications including process control, data acquisition, and monitoring.

SKU: 14122401 Category: Others Tags: NI, NI Motor, SCXI-1520, SCXI-1520 System

Description
Reviews (0)

Description

Brand:NI

Model:SCXI-1520

Module Type:Data Acquisition Module

Input Channels:8 differential or 16 single-ended

Resolution:16 bits

Sampling Rate:Up to 1 MS/s per channel

Input Range:+/- 10V

Analog Output:No

Digital I/O:No

Interface:SCXI-1100 Chassis

Certification:Compliant with IEEE 1451.2 Smart Transducer Interface Standard

The NI SCXI-1520 Analog Input Module is designed for precision data acquisition in demanding industrial environments. With 32 single-ended or 16 differential input channels, this module ensures high accuracy and reliability. Its 16-bit resolution allows for fine-grained measurement of signals, while a sampling rate of up to 250 kS/s per channel guarantees rapid data acquisition. The input range can be adjusted to fit different applications, with options for +/-10V, +/-5V, +/-2.5V, and +/-1.25V. The high input impedance of 1 MΩ minimizes loading effects on the signal source, ensuring accurate readings. For safety and compliance, the module provides 3000 Vrms isolation, meeting CE, UL, CSA, and RoHS standards. Designed with robust construction, the NI SCXI-1520 is built to withstand harsh industrial conditions, providing reliable performance over time.
