Description
The NI (National Instruments) PXIe-5164 PXI oscilloscope is a high-performance oscilloscope device designed for applications that require up to 400 MHz analog bandwidth and flexible measurement configurations. The following is a detailed introduction to the product:
1、 Basic parameters
Model: PXIe-5164
Bandwidth: 400 MHz
Resolution: 14 bits
Sampling rate: up to 1 GS/s (gigabit samples per second)
Number of channels: Supports two or four channels (depending on configuration)
Memory capacity: High capacity onboard memory, supporting large amounts of data collection
2、 Functional Features
High performance sampling: PXIe-5164 provides a sampling rate of up to 1 GS/s, which can accurately capture high-speed signals and meet various high-precision measurement requirements.
Wide analog bandwidth: The 400 MHz analog bandwidth ensures signal integrity and accuracy, making it suitable for various high-frequency signal measurement scenarios.
Flexible configuration: This oscilloscope provides flexible coupling, voltage range, and filtering settings, which users can configure according to their actual needs.
Multi trigger mode: Supports multiple trigger modes, making it convenient for users to accurately trigger and capture based on signal characteristics.
Data flow and analysis functions: Built in instrument drivers provide data flow and analysis functions, supporting users to perform efficient data processing and analysis.
PXI synchronization and data stream transmission: Supports PXI synchronization and data stream transmission functions, facilitating collaborative work with other devices in the PXI system.
User programmable FPGA: With user programmable FPGA functionality, users can program according to specific needs to achieve more complex signal processing and analysis.
3、 Application Fields
The PXIe-5164 PXI oscilloscope is widely used in electronic testing, communication, semiconductor, aerospace and other fields, especially in situations where high-speed and high-precision signal measurement is required. It can help engineers and researchers quickly and accurately capture and analyze signals, improving the efficiency of product development and testing.
