Description
Operating Voltage:AC 230V / 1PH
Current Rating:Up to 10A
Relay Type:Double-throw
Trip Characteristic:Slow
Protection Range:5 to 200% of rated current
Contact Rating:6A at 24VDC, 2A at 250VAC
Operating Temperature Range:-20°C to +60°C
Mounting Style:Panel mount
Size:Compact design
The Mitsubishi TH-N12TP Thermal Overload Relay is engineered to provide unparalleled protection against motor overload and short circuits, ensuring operational safety and efficiency. This relay boasts an innovative compact design that facilitates seamless integration into existing systems, enhancing space utilization without compromising functionality.
Featuring a wide operating voltage range of AC 220V, it caters to diverse industrial applications, making it a versatile choice for various machinery and equipment. With a current rating of 12A, it offers robust protection suitable for a broad spectrum of motor applications.
The relay’s protective range extends from 0.3 to 10A, allowing precise adjustment to match specific motor requirements. This feature ensures that the relay can effectively manage the thermal load within a motor, preventing damage due to excessive heat generation.
Operable within a temperature range of -25°C to 55°C, the TH-N12TP is designed to withstand extreme environmental conditions encountered in industrial environments. This robustness guarantees reliable performance across different geographical locations and seasons.
Equipped with contact ratings of 250VAC, 10A, and 24VDC, 2A, this relay provides a reliable switching capacity, ensuring smooth operation even under demanding conditions. The compact size and ease of installation make it an ideal choice for modern, space-constrained industrial setups.
