Description
Manufacturer:General Electric Multilin
Model Number:269PLUS-120N-120
Software:EnerVista 269
Shipping Dimensions:11.40″ x 7.50″ x 16.00″ (W × H × D)
Shipping Weight:7.75 lb
Switch Inputs:Type Dry Contacts
Temperature Range:-25°C to +60°C ambient
IP Rating:40X
Relay Dimensions:11.25″H, 7.5″W, 5″H
Phase Reversal Relay Response Time:within 3.5 sec. of motor start attempt
Phase Current Inputs:Conversion calibrated RMS
Running Hours Counter Accuracy:±1%
Control Power:Nominal 120 VAC, range: 90-150 VAC
Overload Curves Detection Level:±1% of primary CT amps
Phase Current Input Range:0.05 to 12 × phase CT primary amps setpoint
The GE 269PLUS-120N-120 Motor Management Relay is specifically engineered for industrial motor protection applications.
Its advanced design includes dry contacts for switch inputs, ensuring reliable and efficient motor protection.
Operating within a wide temperature range from -25°C to +60°C, the relay is built to withstand harsh industrial environments.
Featuring a 120 Ohm Nickel RTD for temperature monitoring, the 269PLUS-120N-120 offers comprehensive protection against motor failures.
Additionally, the relay is equipped with various protective features such as speed device protection, undercurrent/minimum load protection, motor/load bearing overtemperature protection, and unbalance protection, making it an essential component in any industrial motor setup.
