Description
Power Supply Voltage:24 VDC
Operating Temperature:-20°C to +70°C
Input Current:20 mA
Output Capacity:5 A per channel
Communication Protocol:Modbus RTU, Ethernet/IP
Relay Contacts:1 Form A, 1 Form C
Dimensions:105mm x 51mm x 34mm
Mounting Type:Panel Mount
Certifications:UL, CE, ISO 9001
The GE IC694MDL645 is a highly versatile modular control system module, specifically engineered for integration into advanced industrial automation systems. Its compact design allows for easy installation within tight spaces, while its robust construction ensures durability in challenging industrial environments.
This module supports a wide range of industrial protocols, facilitating seamless communication with other system components. The inclusion of RS-485 interface enables data exchange at high speeds, crucial for managing complex control tasks in real-time.
With an operating voltage range of 120 VAC and 24 VDC, the IC694MDL645 provides a flexible solution adaptable to various power supply conditions found in industrial settings. Its high current capacity of 1.5 A for input and 3.0 A for output ensures sufficient power delivery to drive motors and actuators efficiently.
In terms of environmental tolerance, the IC694MDL645 is designed to withstand temperatures ranging from -10°C to +60°C, making it suitable for use in extreme climates without compromising performance. The module’s relay contacts are rated for 10 A at both 250 VAC and 24 VDC, offering reliable switching capabilities.
For safety and operational efficiency, the GE IC694MDL645 requires a separate power supply. This ensures that the module operates independently and reliably, minimizing the risk of power disruptions affecting the overall system stability.
