Description
Operating Voltage (V):600V
Continuous Current (A):200A
Switching Frequency (kHz):100
Insulation Resistance (MΩ):≥100
Cooling Method:Thermal Pad & Heat Sink
Operating Temperature Range (-°C to +°C):-40°C to +170°C
Input Signal:PWM or Gate Drive
Output:Power Switching for Motor Control
The EUPEC BSM200GB170DLC IGBT module is engineered to deliver exceptional performance in harsh industrial environments. Its robust design ensures reliability under extreme temperature conditions, from -40°C to +170°C.
With a current rating of 200A and a switching frequency of 10kHz, this module is optimized for applications requiring fast response and high efficiency. It supports wide voltage ranges, making it versatile for various industrial settings.
Featuring high insulation resistance of at least 10^12 Ω, the EUPEC BSM200GB170DLC ensures minimal electrical interference and enhanced safety. The module is equipped with M12 connectors for secure and efficient mechanical connection, facilitating quick installation and maintenance.
Operated within ambient temperatures ranging from -10°C to +50°C, this IGBT module maintains its operational integrity even in changing environmental conditions. It’s designed for long-term reliability, ensuring minimal downtime and maximum productivity in industrial applications.
The compact size of 120 x 70 x 40 mm makes it suitable for space-constrained industrial setups without compromising on performance. The EUPEC BSM200GB170DLC is a strategic choice for enhancing power conversion efficiency and managing energy consumption in industrial control systems.
