Bently Nevada 3500/22 rack interface module

Description

Bently Nevada 3500/22 rack interface module

Product overview
The Bently Nevada 3500/22 is a rack interface module for use in Bentley 3500 Series monitoring systems. The function of this module is to connect the monitoring system to the rack, which is easy to maintain and replace the monitoring system. The 3500/22M replaces the 3500/20M as the interface between the 3500 monitoring system and compatible software such as System 1 status monitoring and diagnostic software and the 3500 system configuration software.

Functional characteristics
The 3500/22M integrates communications processor capabilities to continuously collect steady-state and transient dynamic (waveform) data and transmit this data to host software over an Ethernet link. It has static data capture capabilities, but can also capture dynamic and high-resolution transient data if the disk is enabled using an optional channel. Each 3500 rack requires a TDI or RIM and always occupies slot 1 (next to the power supply).

System compatibility
The 3500/22M is compatible with Bentley 3500 Series monitoring systems and can be used in a variety of application scenarios by connecting to a rack. The module is located in a slot adjacent to the power supply of the 3500 rack and is connected to M-series monitors such as 3500/40M, 3500/42M, etc., for continuous data collection and transmission.

Maintenance and reset
The 3500/22M provides a rack reset button to switch the rack between “RUN” and “PROGRAM” modes. RUN mode prevents configuration modifications while allowing the rack to run properly. By unplugging the key from any location on the rack, the switch can be locked in the run or programmed position, preventing unnecessary rack reconfiguration.

Technical specification
Technical specifications for the 3500/22M include 10.5W power consumption, USB-B front panel, 10Base-T or 100Base-TX Ethernet (adaptive), pre – and post-alarm data, I/O module relays, and more.

Application field
The Bently Nevada 3500/22 rack interface module is widely used in applications requiring continuous monitoring and protection of machinery, especially in oil and gas, oil and gas transmission lines, pulp and paper, metallurgical mining, food and pharmaceutical, Marine engines and other fields.

The Bently Nevada 3500/22 rack interface module is an integral part of Bentley’s 3500 Series monitoring system, providing stable data transmission and flexible system configuration capabilities to ensure the safe operation of machinery.
