Description
Connection Technology:EtherCAT
Number of Channels:8
Nominal Voltage:24 V DC (-15% / +20%)
Rated Load Voltage:0…30 V AC/DC (ohmic load: 0…48 V DC)
Max Output Current:3 A per channel
Peak Current:5 A (100 ms), < 50 A (10 ms)
Protocol:EtherCAT
Response Time:typ. 2 ms (read input/write to K-bus)
Current Consumption K-bus:typ. 80 mA
Weight:approx. 45 g
The Beckhoff EK1122 EtherCAT Terminals are engineered to meet the stringent demands of modern industrial automation environments. Designed with efficiency and reliability at the forefront, these terminals seamlessly integrate into existing systems, enhancing overall productivity and system accuracy.
Each terminal is equipped with dual-channel capabilities, allowing for flexible connections to various devices within an automated system. The robust M8 connector ensures a secure and straightforward installation process, minimizing downtime and simplifying maintenance tasks.
Built from high-quality aluminum alloy, the terminals offer not only durability but also a lightweight design, making them ideal for both stationary and mobile applications. The compact size of 120mm x 30mm x 10mm allows for efficient space utilization without compromising on functionality.
Operating within a temperature range of -25°C to +60°C, the Beckhoff EK1122 EtherCAT Terminals are designed to withstand challenging industrial conditions. This broad temperature range ensures consistent performance throughout the year, regardless of environmental fluctuations.
With its IP20 protection rating, the terminal is suitable for indoor applications, safeguarding against dust and light splashes. The 24V DC power supply guarantees stable operation, ensuring reliable data transfer even under varying electrical conditions.
