Description
Model Type:SLC500
Model Number:1746-NIO4V/A
Manufacturer:Allen Bradley
Module Type:Analog Combination Module
Resolution:High Resolution
Number of Input Channels:2
Number of Output Channels:2
Common Mode Voltage Range (Input):-20 to 20 V
Absolute Input Voltage (Max.):±7.5 VDC or ±7.5 VAC RMS
Input Range (Current):-20 to 20 mA
Absolute Input Current (Max.):-30 to 30 mA
Output Range (Voltage):-10 to 10 V – 1 LSB
Full Scale Output Voltage:10 VDC
Overvoltage Protection (Voltage):7.5 VAC RMS
Output Range (Voltage Control):-10 to 10 VDC – 1 LSB
The Allen Bradley SLC500 1746-NIO4V is a high-performance analog combination module ideal for industrial control systems.
Its design includes two input channels and two output channels, making it a versatile solution for various applications.
With a wide input voltage range of -20 to 20 V and an input current range of -20 to 20 mA, this module ensures precise and reliable data acquisition.
The output range of -10 to 10 V provides accurate control signals, while overvoltage protection ensures long-term reliability.
Additionally, the backplane current draw of 55 mA makes it energy-efficient and easy to integrate into existing systems.
Whether you’re working on manufacturing processes, automation systems, or any other industrial application, the Allen Bradley SLC500 1746-NIO4V delivers the precision and performance needed to meet your needs.
