Description
Module Type:IGBT
Model Number:NINT-45C BSM25GD120DN2
Rated Current:250 A
Rated Voltage:1200 V
Cooling System:Water-cooled
Thermal Resistance:0.15 K/W
Operating Temperature Range:-40°C to +125°C
Insulation Class:F
Number of Diodes:1
Package Type:TO-247-3
Electrical Life:100,000 Cycles
Mechanical Life:50,000 Hours
Control Interface:RS-485
The ABB NINT-45C BSM25GD120DN2 IGBT module stands out for its robust design, engineered to withstand harsh industrial environments. Its high-efficiency operation ensures minimal energy loss, making it ideal for applications requiring precise control over power conversion processes.
Equipped with advanced thermal management capabilities, this module is designed for continuous operation in extreme temperatures ranging from -40°C to +125°C. The water-cooled system ensures efficient heat dissipation, even under heavy loads, thus enhancing its lifespan and reliability.
Featuring an insulation class F, this module can handle high temperatures without compromising on safety or performance. The inclusion of a TO-247-3 package type facilitates easy integration into existing systems, minimizing installation time and complexity.
With a guaranteed electrical life of 100,000 cycles and a mechanical life of 50,000 hours, the NINT-45C BSM25GD120DN2 IGBT module promises long-term durability and maintenance-free operation. This makes it a preferred choice for industries requiring reliable power solutions with low lifecycle costs.
The RS-485 control interface offers versatile communication options, enabling seamless integration with various control systems. This feature ensures precise monitoring and control over the module’s performance, facilitating easy diagnostics and troubleshooting when needed.
