Description
Power Rating:1000W
Voltage Rating:DC 1200V
Current Rating:800A
Switching Frequency:20kHz
Thermal Resistance:≤2.5°C/W
Cooling Method:Thermal Pad + Heat Sink
Operating Temperature Range:-40°C to +175°C
Protection Features:Overcurrent, Overvoltage, Overheating
Insulation Class:F
The ABB 5SNS 0100W120000 IGBT Module boasts superior power density, enabling it to handle complex industrial tasks with ease and reliability. Its robust design ensures longevity under harsh conditions, making it an ideal choice for heavy-duty applications requiring precise control and energy-efficient performance.
Equipped with advanced semiconductor technology, this module offers unparalleled switching speeds and efficiency, optimizing energy consumption and reducing heat dissipation. It’s suitable for a wide range of applications including motor drives, renewable energy systems, and industrial automation processes.
With its high switching frequency, the ABB IGBT Module ensures minimal harmonic distortion, which is crucial for maintaining the integrity of electrical systems and minimizing wear on connected equipment. Its wide operating temperature range allows it to function reliably in diverse environmental conditions.
The thermal management system, featuring a thermal pad and heat sink, ensures efficient heat dissipation, preventing overheating and maintaining optimal operational performance. This feature, combined with its rugged construction, contributes to its reliability and durability over long periods of use.
Certified to international safety and quality standards, including CE, UL, and IEC, the ABB 5SNS 0100W120000 IGBT Module adheres to stringent industry regulations, providing peace of mind for users. Its compatibility with a wide range of control systems makes it a versatile addition to any industrial setup.
