Description
Input Voltage Range:24V DC
Common Mode Voltage Range:-20 to +20 VDC
Absolute Input Voltage:±7.5 VDC or ±7.5 VAC RMS (Max.)
Input Range:-20 to +20 mA
Isolation:500 VDC
Number of Channels:8
Operating Voltage:5 to 30V DC or 5 to 250V AC
Current Rating:Backplane Current Draw: 35mA at 5V, 85mA at 24V
The Allen-Bradley 1746-IV8 DC Input Module is engineered for demanding industrial environments, offering unparalleled reliability and precision in data acquisition. Its robust design withstands harsh conditions, ensuring uninterrupted operation in various manufacturing settings.
This module supports an expansive input voltage range, making it suitable for a multitude of applications from small to large-scale operations. Its ability to handle common mode voltages within the -20 to +20 VDC spectrum ensures compatibility with a wide array of sensors and devices.
Equipped with 8 high-resolution channels, the 1746-IV8 allows for flexible and precise control over industrial processes. The module’s high-precision input capabilities are complemented by its ability to process data swiftly and accurately, enhancing overall system efficiency.
Withstanding isolation levels of up to 500 VDC, the 1746-IV8 provides excellent electrical safety, protecting against potential electrical hazards in industrial setups. This feature is crucial in safeguarding personnel and equipment from damage due to short circuits or other electrical faults.
The module is compatible with Allen-Bradley’s ControlLogix family of controllers, integrating seamlessly into existing automation systems. This compatibility ensures ease of installation and maintenance, reducing downtime and streamlining the operational workflow.
