AB 1746-IV16 Analog Input Module

Description

Type:Analog Input Module

Model:1746-IV16

Manufacturer:Allen-Bradley

Series:SLC 500

Inputs:16 channels

Input Voltage:24VDC

Voltage Range:-10VDC to +10VDC

Accuracy:+/- 1% of full scale

Resolution:12-bit

Current Consumption:Backplane: 0.4A @ 24VDC

Operating Temperature:-40°C to +70°C

Isolation Voltage:500VDC

Communication Interface:RS-485

Power Supply:DC Power Required

Dimensions:130mm x 100mm x 40mm

Weight:0.4kg

    The AB 1746-IV16 Analog Input Module is an essential component for any industrial automation setup, providing unparalleled precision and reliability in data collection.

    With its high-resolution, multi-channel design, this module ensures accurate and consistent readings across various industrial applications, making it suitable for environments requiring high sensitivity and responsiveness.

    Built with robust materials and advanced technology, the AB 1746-IV16 is designed for long-term durability and minimal maintenance, ensuring smooth operation in demanding industrial conditions.

    Installation is straightforward and compatible with all Allen-Bradley SLC 500 series controllers, allowing for quick integration without requiring extensive setup or additional hardware.

    This input module supports a wide range of voltage inputs, from -20 to +20 VDC, making it adaptable to different industrial standards and ensuring compatibility across various equipment and systems.
