Description
1756-IM16I input module modular design
The 1756-IM16I is an input module manufactured by Allen-Bradley (Rockwell Automation) for use in ControlLogix controllers. It is a modular input module that provides 16 isolated digital input channels for monitoring and connecting various industrial sensors and switches.
Main features:
Type: 1756-IM16I
Manufacturer: Allen-Bradley (Rockwell Automation)
Function: Input module
Number of channels: 16 isolated digital input channels
Input type: Digital (sink or purchase)
Input voltage range: 24 VDC (nominal)
Input current: 10 mA (Max)
Response time: 2.5ms (typical)
Applications: Industrial automation, process control, discrete manufacturing and machine control
Benefits:
Modular design: With a modular design, it is easy to extend and customize input functions.
Isolated input: Provides isolated input channels to prevent electrical noise and ground faults.
High-speed response: provides fast response time for real-time processing of input signals.
Wide range of applications: Suitable for various industrial applications involving digital sensors and switches.
Other points to note:
System configuration: Correctly configure the 1756-IM16I module to match the specific input signal characteristics, filtering requirements, and communication parameters of the application.
Wiring and installation: Follow proper wiring and installation practices to ensure safe and reliable module operation.
Programming and configuration: Create the necessary input logic and configure module Settings with Rockwell Automated programming tools.
Maintenance and troubleshooting: Perform regular maintenance checks and follow the manufacturer’s recommended troubleshooting procedures to ensure maximum performance and service life of the 1756-IM16I module.
